16 Mhz Crystal YSX531SL – YXC – SMD

SKU: S3FBIBHXQ2
The 16 MHz Crystal YSX531SL – YXC – SMD is a high-precision surface-mount quartz crystal designed to provide a stable and accurate clock signal for digital electronic circuits. Operating at a frequency of 16 MHz, this crystal is commonly used in microcontrollers, embedded systems, communication devices, and timing-sensitive applications where reliable frequency generation is essential. Built using high-quality quartz technology,...
Rs. 25.00
Rs. 9.00 Rs. 25.00
Sold out
Tax included. Shipping calculated at checkout.
Guaranteed safe & secure checkout

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

Specifications:

Product Type: Quartz Crystal Resonator
Model: YSX531SL
Manufacturer: YXC
Frequency: 16 MHz
Package Type: SMD (Surface Mount Device)
Frequency Stability: High Stability
Oscillation Mode: Fundamental Mode
Load Capacitance: Typically 18pF (depending on variant)
Mounting Type: Surface Mount (SMT)
Operating Temperature Range: Typically -20°C to +70°C

Additional Resources

16 Mhz Crystal SMD.PDF

FAQ

1. What is the operating frequency of the YSX531SL crystal?

The YSX531SL is a 16 MHz SMD crystal oscillator, providing a stable clock signal for microcontrollers, processors, and digital electronic circuits.

2. What is the primary function of a 16 MHz crystal?

A 16 MHz crystal generates a precise timing reference used for clock generation, synchronization, communication protocols, and accurate operation of digital systems.

3. Which devices commonly use a 16 MHz crystal?

A 16 MHz crystal is commonly used in microcontrollers such as ATmega328P, Arduino boards, embedded systems, communication modules, and various digital control circuits.

4. What are the advantages of the SMD package?

The SMD package offers a compact footprint, improved reliability, reduced PCB space requirements, and compatibility with automated assembly processes, making it ideal for modern electronic designs.

5. What applications is the YSX531SL 16 MHz crystal suitable for?

This crystal is suitable for microcontroller clock circuits, embedded systems, industrial controllers, communication devices, consumer electronics, IoT products, and timing-sensitive digital applications.

View full product details

The 16 MHz Crystal YSX531SL – YXC – SMD is a high-precision surface-mount quartz crystal designed to provide a stable and accurate clock signal for digital electronic circuits. Operating at a frequency of 16 MHz, this crystal is commonly used in microcontrollers, embedded systems, communication devices, and timing-sensitive applications where reliable frequency generation is essential.

Built using high-quality quartz technology, the YSX531SL crystal delivers excellent frequency stability, low power consumption, and dependable long-term performance. Its compact SMD package makes it suitable for modern PCB designs that require efficient space utilization and automated assembly processes.
