Pitch Female Berg Strip Header (Right Angle) 1x40 2.54mm

SKU: 7928N6XLDH
This 40×1 Right-Angle Female Berg Strip Connector features the industry-standard 2.54mm pitch and is designed for direct soldering onto printed circuit boards (PCBs). It is ideal for extending connections of microcontrollers, ICs, and other electronic modules, making it a reliable choice for various electronic applications. The connector is bent at a 90-degree angle, allowing horizontal connections from the PCB surface....
Rs. 39.00
Rs. 49.00 Rs. 39.00
Save Rs. 10
Sold out
Tax included. Shipping calculated at checkout.
Guaranteed safe & secure checkout

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

Specifications:

Connector Type: Header Strip
Gender: Female
Mounting Type: Through-Hole
Number of Pins: 40
Pin Pitch: 2.54 mm
Contact Resistance: 20 mΩ
Insulation Resistance: 1000 MΩ
Dimensions: 103 × 2.4 × 8 mm
Weight: 1 gram

Additional Resources

1x40 2.54mm Pitch Female Berg Strip Header.PDF

FAQ

1: What is a 1×40 2.54mm Pitch Female Berg Strip Header (Right Angle) used for?

It is used to create horizontal socket connections on PCBs, allowing easy interfacing with male headers, microcontrollers, ICs, and modules.

2: What does the right-angle (90°) design offer?

The 90° bent design allows connections to extend parallel to the PCB, making it ideal for compact layouts and space-saving designs.

3: Is this connector compatible with standard pin headers?

Yes, with a 2.54mm pitch, it is fully compatible with standard male headers, breadboards, and most electronic modules.

4: Can the 40-pin strip be customized?

Yes, the strip can be cut into smaller sections to match the required number of pins for your specific application.

5: What type of mounting does it require?

 It is designed for through-hole mounting, meaning it needs to be soldered onto a PCB for a secure and stable connection.

View full product details

This 40×1 Right-Angle Female Berg Strip Connector features the industry-standard 2.54mm pitch and is designed for direct soldering onto printed circuit boards (PCBs). It is ideal for extending connections of microcontrollers, ICs, and other electronic modules, making it a reliable choice for various electronic applications.

The connector is bent at a 90-degree angle, allowing horizontal connections from the PCB surface. This design is especially useful in prototyping, compact circuit layouts, and custom PCB designs. It is widely used in electronics, including computer hardware, breadboard setups, and embedded systems.

These connectors can be easily cut into smaller sections to meet specific pin requirements, making them highly flexible for custom applications. They are commonly used as general-purpose headers in both prototyping and production environments.

For a secure and stable connection, the pin size should match the PCB hole dimensions. Proper alignment ensures a firm fit and prevents loosening. Based on your requirement, you can select the appropriate number of pins and spacing, then solder or insert the connector into a breadboard or PCB to establish reliable electrical connections
