Tactile Push Button Switch 6X6X8mm

SKU: JP2933FK0E
The Tactile Push Button Switch 6×6×8mm is a low-profile momentary switch designed for compact electronic applications where space-saving is essential. It provides a clear tactile response when pressed, ensuring reliable user input with a distinct “click” feedback. With its compact 6mm × 6mm base and short 8mm actuator height, this switch is ideal for slim and low-profile PCB designs, handheld...
Rs. 5.00
Rs. 8.00 Rs. 5.00
Save Rs. 3
Sold out
Tax included. Shipping calculated at checkout.
Guaranteed safe & secure checkout

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

Specifications:

Product Type: Tactile Push Button Switch
Body Size: 6mm × 6mm
Actuator Height: 8mm
Switch Type: Momentary
Contact Configuration: Normally Open (NO)
Number of Pins: 4
Mounting Type: Through-Hole PCB Mount

Additional Resources

Tactile Push Button.PDF

FAQ

1. What is a 4-pin DIP tactile push button switch?

It is a compact momentary switch with four pins designed for PCB mounting. It is commonly used as an input button in electronic circuits and projects.

2. How does this tactile switch operate?

The switch is normally open (NO). When pressed, it temporarily closes the circuit (ON), and when released, it returns to its original open state (OFF).

3. Why does the switch have 4 pins instead of 2?

The 4 pins are internally connected in pairs, providing better mechanical stability and secure mounting on the PCB. Electrically, it still functions like a 2-pin switch.

4. What are the common applications of this switch?

It is widely used in:

  • DIY electronics projects
  • Microcontroller inputs (Arduino, ESP32, etc.)
  • Remote controls
  • Keypads and user interfaces
  • Consumer electronics devices

5. What are the advantages of this tactile push button switch?

  • Compact size (6X6X8 mm)
  • Reliable momentary operation
  • Provides tactile feedback when pressed
  • Easy PCB mounting (DIP type)
View full product details

The Tactile Push Button Switch 6×6×8mm is a low-profile momentary switch designed for compact electronic applications where space-saving is essential. It provides a clear tactile response when pressed, ensuring reliable user input with a distinct “click” feedback.

With its compact 6mm × 6mm base and short 8mm actuator height, this switch is ideal for slim and low-profile PCB designs, handheld devices, and compact embedded systems. It operates as a normally open (NO) switch and returns to its default state immediately after release.

This switch is widely used in consumer electronics, portable devices, Arduino projects, control interfaces, and DIY electronics due to its small size, durability, and ease of integration.

Key Features

  • Ultra-compact 6mm × 6mm footprint
  • Low-profile 8mm actuator height
  • Momentary push button operation
  • Clear tactile click feedback
  • Normally Open (NO) contact type
  • 4-pin through-hole PCB mounting
  • Suitable for space-constrained designs
  • High reliability and long mechanical life
