Arduino LCD TFT01 Shield for Mega Board compatible

SKU: D05IWOX7C5
This TFT01 Shield for Arduino Mega compatible boards allows you to directly plug the TFT01 display module into the shield and mount it securely onto the Mega board. The TFT01 LCD supports 8-bit mode and enables simultaneous use of both the SD card interface and the touchscreen interface. It incorporates IC-based voltage division to ensure improved display stability and reliable...
Rs. 259.00
Rs. 299.00 Rs. 259.00
Save Rs. 40
Sold out
Tax included. Shipping calculated at checkout.
Guaranteed safe & secure checkout

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

 Specifications:

Shield Type: TFT01 LCD Shield
Compatibility: Designed for Arduino Mega 2560 compatible boards
Operating Voltage: 3.3V
Operating Mode: 16-bit mode
Dimensions: 8 × 5 × 1 cm
Weight: 15 grams

Additional Resources

LCD TFT01 Shield for Mega.PDF

FAQ

1. What is the TFT01 Shield for Mega?

The TFT01 Shield is an interface board designed to connect large TFT LCD modules directly to Arduino Mega compatible boards. It allows easy mounting and reliable communication between the display and the Mega board.

2. Does it support both SD card and touchscreen at the same time?

Yes. When used with an Arduino Mega 2560, the shield allows simultaneous operation of both the SD card interface and the touchscreen interface without conflict.

3. Why is it better suited for Mega boards instead of UNO?

Large TFT displays require more data pins and memory. The Arduino Mega 2560 provides additional I/O pins and higher memory capacity, making it more suitable for large TFT modules.

4. Does it require soldering?

No. The shield is designed for direct plug-and-play mounting onto the Mega board.

5. What display modes are supported?

The shield supports both:
8-bit mode
16-bit mode (recommended for better performance on Mega boards)

View full product details

This TFT01 Shield for Arduino Mega compatible boards allows you to directly plug the TFT01 display module into the shield and mount it securely onto the Mega board. The TFT01 LCD supports 8-bit mode and enables simultaneous use of both the SD card interface and the touchscreen interface. It incorporates IC-based voltage division to ensure improved display stability and reliable performance.

The TFT01 LCD Shield V2.0 is specifically designed for Mega boards compatible with Arduino and is ideal for use with 3.2-inch, 4.3-inch, 5-inch, and 7-inch TFT LCD modules.

Additionally, the TFT01 LCD now supports 16-bit mode on the Mega2560, eliminating limitations commonly faced with ATmega328-based boards. This allows both the SD card and touchscreen interfaces to function together without conflicts.
