Specifications:

• Product: Arduino NANO Compatible
• Model: Nano V3.0 (CH340 Series)
• Microcontroller: ATmega328P (8-bit AVR)
• Architecture: High-performance RISC
• Operating Voltage: 5V (Logic Level)
• Clock Speed: 16MHz Precision Crystal Oscillator
• Memory Configuration: 32KB Flash (2KB reserved for Bootloader)
• SRAM / EEPROM: 2KB / 1KB
• Input Voltage (Limit): 6V – 20V (Via Vin Pin)
• Input Voltage (Recommended): 7V – 12V
• USB Interface: Integrated USB Type-C Port (CH340 Driver)
• Digital I/O Pins: 22 Total (Including 6 PWM Outputs)
• Analog Input Channels: 8 Ports (A0 – A7)
• DC Current per I/O Pin: 40mA (Maximum)



1. What is the difference between Uno and Nano?

The difference between these two is the size. Because the Arduino Uno board is twice the size of the Arduino Nano board. As a result, Uno boards take up more room on the system. UNO can be programmed using a USB cable, whereas Nano requires a mini USB cable. The most notable difference between the two is that the Uno has 1.5 kB more available program memory due to a smaller boot section.

2. Should I buy Uno or Nano?

If the project is simple with low cost and a small profile it is better to go with Nano and it can be used in portable electronics and sensor gathering. Uno is the best choice for desktop prototyping with ethernet shields, and they can also be used in IoT sensors.

3. What is Nano Arduino?

The Nano is a small, complete, and breadboard-friendly board based on the ATmega328P released in 2008. It has the same connectivity and specifications as the Arduino Uno board but in a smaller form factor.

4. What is Nano R3 Development Board?

The Nano is a small, complete, and breadboard-friendly board based on the ATmega328 (Arduino Nano 3. x). It has more or less the same functionality as the Arduino Duemilanove but in a different package. It only has a DC power jack and uses a Mini-B USB cable rather than a standard one.

5. How many digital pins are there on the Nano board?

Each of the 14 digital pins on the Nano can be used as an input or output, using pinMode(), digitalWrite(), and digitalRead() functions. They operate at 5 volts.

6. Is this Nano Development board compatible with the official Arduino?

The Nano development board is the smallest, most complete, and breadboard-friendly board and 100% compatible with the official Arduino Nano card, and fully compatible with Windows, Mac, and Linux operating systems. It uses the chip ATmega328P CH340 instead of FT232RL. You can start with various electronic projects by using the Arduino software (IDE)

7. Is Bluetooth available on the Nano Development Board?

Yes. The Arduino Nano's main microprocessor is an ATmega328P, which communicates with the serial port to send and receive Bluetooth packets from the CC2540 BLE chip. This results in a Bluetooth-enabled Arduino device housed in a Nano-sized circuit board!
