Capacitive Touch Sensor Module-TTP223

SKU: H2INOKG6NI
The TTP223 Capacitive Touch Sensor Module is a compact touch-sensitive input module designed to replace traditional mechanical push buttons. Based on the TTP223 capacitive touch sensing IC, the module detects the touch of a finger through changes in capacitance and generates a digital output signal. Unlike mechanical switches, the TTP223 provides silent operation, high reliability, and long service life since...
Rs. 19.00
Rs. 25.00 Rs. 19.00
Save Rs. 6
Sold out
Tax included. Shipping calculated at checkout.
Guaranteed safe & secure checkout

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

Specifications:

Module Type: Capacitive Touch Sensor Module
Sensor IC: TTP223
Detection Method: Capacitive Touch Sensing
Operating Voltage: 2.0V to 5.5V DC
Typical Operating Voltage: 3.3V to 5V DC
Operating Current: Typically Less Than 10µA (Standby)
Output Type: Digital Output
Output Logic: Active High (Default)
Response Time: Approximately 60ms
Touch Pad Type: Capacitive Touch Electrode
Sensitivity: High Sensitivity Touch Detection
Indicator LED: Yes
Interface Pins: VCC, GND, OUT
Auto Calibration: Yes
Power Consumption: Ultra Low Power
Operating Temperature Range: -20°C to +70°C
Storage Temperature Range: -40°C to +85°C
Module Dimensions: Approximately 24mm × 24mm × 7mm
Mounting Type: PCB Module
Compatibility: Arduino, ESP32, STM32, Raspberry Pi Pico, AVR, PIC
