DPDT 6 Pin Toggle Switch ON-OFF-ON (15A 250V)

SKU: YNNI6CDIDT
This ON-OFF-ON DPDT toggle switch features a durable construction with a metal and bakelite body. The shaft and mounting bracket are crafted from brass, while the terminals are made of copper for reliable conductivity. It combines a sleek, compact design with robust build quality, making it ideal for various electrical applications. Applications: Switching lights and electrical circuits at home Industrial...
Rs. 109.00
Rs. 139.00 Rs. 109.00
Save Rs. 30
Sold out
Tax included. Shipping calculated at checkout.
Guaranteed safe & secure checkout

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

Specifications:

Switch Type: DPDT Toggle Switch
Rated Current: 15A
Rated Voltage: 250V AC
Dimensions (L x W x H): 34 x 20 x 45 mm

Additional Resources

DPDT 6 Pin Toggle Switch ON-OFF-ON.PDF

FAQ

1. What type of switch is the DPDT 6 Pin Toggle Switch?

 It is a Double Pole Double Throw (DPDT) toggle switch with an ON-OFF-ON configuration, allowing control of two separate circuits with a single switch.

2. What is the maximum voltage and current rating of this switch?

 This switch can handle up to 15A at 250V AC, making it suitable for heavy-duty electrical loads.

3. How many pins does the switch have and what are they for?

 The switch has 6 pins: two sets of three terminals, each set controlling one pole of the DPDT configuration. The center pin in each set is the common, and the two side pins are the switched outputs.

4. What are the key features of this toggle switch?

  • ON-OFF-ON functionality for dual control options
  • Robust construction suitable for industrial and DIY projects
  • Panel-mountable with threaded bushing and nut
  • High current rating for demanding applications

5. Where can this DPDT toggle switch be used?

 It is commonly used in:

  • Polarity reversal for motors
  • Robotics and automation projects
  • Industrial machinery
  • DIY electrical control panels
  • Applications requiring dual circuit switching with a clear ON/OFF/ON operation
View full product details

This ON-OFF-ON DPDT toggle switch features a durable construction with a metal and bakelite body. The shaft and mounting bracket are crafted from brass, while the terminals are made of copper for reliable conductivity. It combines a sleek, compact design with robust build quality, making it ideal for various electrical applications.

Applications:

  • Switching lights and electrical circuits at home
  • Industrial machinery and equipment control
  • Electrical toys and hobby projects
  • Automotive uses such as headlights, fog lamps, dome lights, and other auxiliary circuits
