Finger Heartbeat Detection Sensor Module (KY-039)

SKU: SSXRMXDMDI
★★★★ ★ ★
4.3 (32 reviews)
The Finger Heartbeat Detection Sensor Module is a compact biosensing module designed to measure heartbeats by detecting changes in blood volume within a finger using an infrared LED and photodetector. Based on the principle of photoplethysmography (PPG), the sensor monitors variations in blood flow caused by heart contractions and generates corresponding pulse signals. The module features onboard signal conditioning circuitry...
Rs. 49.00
Rs. 55.00 Rs. 49.00
Save Rs. 6 Incl. GST (No Hidden Charges)
Sold out
Tax included. Shipping calculated at checkout.
COD Available
Easy Return
Quality Assured
12 people are viewing this right now
Secure Checkout With
Bulk Orders Available
Special Pricing for Schools, Colleges & Businesses
Contact Us
Free Delivery For All Prepaid Orders Above ₹999
Shop for ₹999 or more and get FREE delivery
across India.
FREE
View full product details
Same Day Dispatch Order before 2PM
Pan India Delivery Shipping in 24-48H
Secure Packaging Safe & Damage Free
Dedicated Support Expert Assistance

The Finger Heartbeat Detection Sensor Module is a compact biosensing module designed to measure heartbeats by detecting changes in blood volume within a finger using an infrared LED and photodetector. Based on the principle of photoplethysmography (PPG), the sensor monitors variations in blood flow caused by heart contractions and generates corresponding pulse signals.

The module features onboard signal conditioning circuitry and provides both analog and digital outputs, making it easy to interface with Arduino, ESP32, STM32, Raspberry Pi Pico, and other microcontroller platforms. An onboard LED indicator flashes in sync with detected heartbeats, providing visual feedback during operation.

This sensor is widely used in health monitoring projects, fitness devices, biomedical experiments, wearable electronics, and educational electronics applications.

Key Features

  • Detects human heartbeat through fingertip measurement
  • Based on photoplethysmography (PPG) technology
  • Infrared LED and photodetector sensing system
  • Analog and digital signal outputs
  • Onboard heartbeat indication LED
  • Adjustable sensitivity via onboard potentiometer
  • Fast response and stable performance
  • Easy interfacing with microcontrollers
  • Low power consumption
  • Compact PCB design
  • Real-time pulse detection
  • Suitable for educational and biomedical projects
  • Compatible with Arduino, ESP32, STM32, and Raspberry Pi
  • Simple plug-and-play operation
