Mercury Tilt Switch Module (KY-017)

SKU: PC9XEU1A1Q
The KY-017 Mercury Tilt Switch Module is a simple orientation and motion detection module that uses a mercury tilt switch to detect changes in position or inclination. When the module is tilted beyond a certain angle, the mercury inside the switch flows and creates an electrical connection, changing the output state. The module provides a digital output signal that can...
Rs. 33.00
Rs. 36.00 Rs. 33.00
Save Rs. 3
Sold out
Tax included. Shipping calculated at checkout.
Guaranteed safe & secure checkout

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

Specifications:

Module Type: Mercury Tilt Switch Sensor Module
Model: KY-017
Sensor Type: Mercury Tilt Switch
Detection Method: Mechanical Tilt Detection
Operating Voltage: 3.3V to 5V DC
Operating Current: Less Than 10mA
Output Type: Digital Output
Signal Logic: TTL Compatible
Switch Type: Mercury Contact Switch
Response Time: Real-Time Detection
Interface Pins: VCC, GND, S
Sensitivity: High Tilt Sensitivity
Detection Function: Tilt and Orientation Detection
Indicator LED: Yes
Operating Angle: Orientation Dependent
Mounting Type: Through-Hole Module
PCB Dimensions: Approximately 18.5mm × 15mm
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Compatibility: Arduino, ESP32, STM32, Raspberry Pi Pico, AVR, PIC
