Tactile Push Button Switch 6X6X7mm

SKU: 0DAASJT3MY
★★★★ ★ ★
4.7 (54 reviews)
The 6×6×7mm Tactile Push Button Switch is a compact momentary contact switch designed for precise and reliable user input in electronic circuits. It operates in a normally open (NO) configuration, meaning the circuit remains open until the button is pressed and closes only during actuation. With its low-profile 7mm height, this switch is ideal for compact PCB designs where space...
Rs. 6.00
Rs. 8.00 Rs. 6.00
Save Rs. 2 Incl. GST (No Hidden Charges)
Sold out
Tax included. Shipping calculated at checkout.
COD Available
Easy Return
Quality Assured
12 people are viewing this right now
Secure Checkout With
Bulk Orders Available
Special Pricing for Schools, Colleges & Businesses
Contact Us
Free Delivery for all orders above ₹999
Shop for ₹999 or more and get FREE delivery
across India.
FREE
View full product details
Same Day Dispatch Order before 2PM
Pan India Delivery Shipping in 24-48H
Secure Packaging Safe & Damage Free
Dedicated Support Expert Assistance

The 6×6×7mm Tactile Push Button Switch is a compact momentary contact switch designed for precise and reliable user input in electronic circuits. It operates in a normally open (NO) configuration, meaning the circuit remains open until the button is pressed and closes only during actuation.

With its low-profile 7mm height, this switch is ideal for compact PCB designs where space is limited but a slightly taller actuator than ultra-low-profile variants is required. It delivers a crisp tactile response, making it suitable for consumer electronics, embedded systems, Arduino projects, DIY circuits, and control interfaces.

Key Features

  • Compact 6×6mm footprint with 7mm height profile
  • Momentary ON (Normally Open) switching action
  • Clear tactile feedback for accurate input
  • Through-hole PCB mounting design
  • Suitable for compact and low-profile electronic devices
  • High durability with stable performance
  • Low contact resistance for reliable switching
  • Compatible with Arduino, IoT, and embedded systems

Shipping & Returns

Orders placed before 3 PM IST will be shipped on the same day (excluding Sundays and Public holidays) through our shipping partners. In rare cases, the pickup may get delayed during Public holidays / Bandh / Environmental disturbances.

Specifications

Specifications:

Body Material: Plastic
Switch Type: Push Button
Number of Pins: 4
Operating Voltage: 12V DC
Operating Current: 50mA
Actuator Shape: Round
Contact Material: Brass
Contact Resistance: 50 mΩ
Insulation Resistance: 100 MΩ
Operating Temperature Range: -30°C to +70°C
Actuation Force: 180 gf
Push Button Dimensions (L × W × H): 6X6X7 mm

Additional Resources

Tactile Push Button.PDF

FAQ

1. What is a 6×6×7mm tactile push button switch used for?

It is used as a momentary input switch in electronic circuits such as Arduino projects, embedded systems, consumer electronics, and control panels.

2. How does the 6×6×7mm tactile switch work?

It works on a normally open (NO) mechanism. The circuit is completed only when the button is pressed and breaks immediately when released.

3. Can this switch be used on a PCB?

Yes, it is designed for through-hole PCB mounting and is widely used in PCB-based electronic designs and prototyping boards.

4. What makes the 7mm version different from other sizes?

The 7mm height provides a balanced profile—higher than ultra-low versions (6mm) but still compact, making it suitable for moderately enclosed or accessible panel designs.

5. Is this switch suitable for Arduino and DIY electronics projects?

Yes, it is highly suitable for Arduino, Raspberry Pi, and other microcontroller-based projects due to its reliability, compact size, and tactile response.
